XLERATOReco® Hand Dryers

Scroll over images on right to enlarge

Model XL-SB-ECO
Surface-mounted, Automatic,
Brushed Stainless Steel Cover

  • XLERATOR High Speed Energy Efficient Hand Dryer Model XL-BW-ECO
  • XLERATOR High Speed Energy Efficient Hand Dryer Model XL-W-ECO
  • XLERATOR High Speed Energy Efficient Hand Dryer Model XL-GR-ECO
  • XLERATOR High Speed Energy Efficient Hand Dryer Model XL-SP-ECO
  • XLERATOR High Speed Energy Efficient Hand Dryer Model XL-SI-ECO
  • XLERATOR High Speed Energy Efficient Hand Dryer Model XL-C-ECO
  • XLERATOR High Speed Energy Efficient Hand Dryer Model XL-SB-ECO

Model No. Cover Finish Mounting Time Cycle Dryer Type ProductTAG
XL-BW-ECO White Thermoset (BMC) Surface Automatic Hand Dryer
XL-W-ECO White Surface Automatic Hand Dryer
XL-GR-ECO Graphite Surface Automatic Hand Dryer
XL-SP-ECO** Custom Special Paint Surface Automatic Hand Dryer
XL-SI-ECO* Custom Special Image Surface Automatic Hand Dryer
XL-C-ECO Chrome Surface Automatic Hand Dryer
XL-SB-ECO Brushed Stainless Steel Surface Automatic Hand Dryer

*Note: Exclusive digital image technology allows for the addition of Company, School or Team logos with any color, design or a 'Green message'. ** Special Paint powder coated covers come in many colors and textures.

ENHANCED FEATURES

  • Adjustable Speed & Sound
  • Multi Voltage: 110-120V, 208-277V, 230V
  • Externally Visible Service LED To Assist With Troubleshooting (See Owner's Manuel For Codes)

FEATURES

  • New No Heat Technology
  • 10 Second Dry Time*
  • 500 Watts
  • Can Install Multiple XLERATOReco Units On One Circuit
  • 95% Cost Savings Vs. Paper Towels
  • 5-Year Limited Warranty
  • Made In USA Certified®
  • BuildingGreen® Listed and Helps Qualify for several LEED®credits
  • Virtually Maintenance Free

SPECIFICATIONS

Dimensions:

Width 11 3/4" (298 mm)
Height 12 11/16" (322 mm)
Depth 6 11/16" (170 mm)

Weight:

XL-BW-ECO: 15 lbs. (6.8 kgs.)
XL-SB-ECO: 16 lbs. (7.26 kgs.)
XL-W-ECO, GR-ECO, C-ECO, SI-ECO, SP-ECO: 17 lbs. (7.71 kgs.)

CONSTRUCTION

  1. All covers will be fastened to a base plate by two chrome plated tamper-proof bolts. Cover shall be one of the following:
    Die-cast zinc alloy - One-piece, heavy-duty, rib-reinforced, lightweight, unbreakable, rustproof and all exposed surfaces shall be bright chrome plated or finished with chip-proof, electrostatically applied epoxy paint.
    Bulk Molding Compound (BMC) – White reinforced thermoset resin.
    Stainless Steel – with a brushed finish.
    Special Image – Digital image applied to die-cast or stainless steel covers using patented Kolorfusion Sublimation Decoration process.
  2. Base plate shall be equipped with (3) 7/8" (22 mm) diameter holes, the bottom one is suitable for use with surface conduit.
  3. All internal parts shall be coated according to Underwriters' Laboratories, Inc. requirements.
  4. Entire mechanism shall be internally grounded.
  5. Options
    HEPA Filtration System: Filters 99.97% of bacteria at 0.3 microns from the air stream. 1.1 Noise Reduction Nozzle: Lowers decibel level 9 dB by reducing air deflection noise but increases dry time by approximately 3 seconds.
  6. Accessories (optional)
    Microban® Antimicrobial Wall Guards: 89W (White), 89B (Black), 89S (Stainless)
    XChanger Paper Towel Retrofit Kit: 40550, 40551 (ADA Height)
    ADA Recess Kit: 40502

MECHANISM

  1. Motor shall be a thermally protected, series commutated, through-flow discharge vacuum motor/blower (5/8 hp / 20,000 rpm) which provides air velocity of up to 19,000 LFM (linear feet per minute) at the air outlet and 16,000 LFM at the hands (4 inches [102 mm] below air outlet).
  2. Control assembly is activated by an infrared optical sensor located next to the air outlet. The dryer shall operate as long as hands are under the air outlet. Control includes a speed and sound control mechanism and a filter sensor which is activated should the filter become clogged. There is a 35-second lockout feature if hands are not removed. Sensor equipped with externally visible Red LED light that can flash error codes to assist in troubleshooting.

LIMITED WARRANTY

The dryer shall be guaranteed to be free from defects for a period of five (5) years. Warranty shall include labor performed at factory as well as the repair or exchange of defective parts, at manufacturer's option.

QUANTITY RECOMMENDATIONS

One dryer for every two washbasins is sufficient for most applications. If restroom traffic is unusually heavy, we suggest one dryer per washbasin in small installations and two dryers for every three washbasins in larger installations. When a 54" washfountain is used, we suggest four to five dryers.

HAND DRYING PROCEDURE

Please contact Excel at or 413-525-4531 for Excel's recommended hand drying procedure.

ELECTRICAL

VOLTS AMPS WATTS HERTZ *
110-120V 4.3-4.5A 460-530W 50/60 Hz
208-277V 2-2.2A 425-500W 50/60 Hz
230V 2.2A 500W 50 Hz

SUGGESTED MOUNTING HEIGHTS

From Floor to Bottom of Dryer
Men 45" (114 cm)
Women 43" (109 cm)
Teenagers 41" (104 cm)
Children 35" (89 cm)
Accessibility 37" (94 cm)

SmartBIM

1 This certificate applies to all XLERATOR models except XL-SB.
2 This certificate only applies to model XL-SB.

HEPA Filtration System

Part ID Description Download PDF ProductTAG
40525 XLERATOR HEPA Filter Retro Fit Kit
40520 XLERATOR HEPA Filter Replacement
94 HEPA Pre-Filter Replacement, Metal Mesh

XLERATOR XChanger™ Kit

Part ID Description Download PDF ProductTAG
40550 XChanger Kit
40551 ADA Height XChanger Kit
40575 XChanger Combo Kit: Comes with ADA Recess Kit #40502 and Standard XChanger #40550
40576 ADA XChanger Combo Kit: Comes with ADA Recess Kit #40502 and ADA Height XChanger #40551

Anti-Microbial Wall Guards

Part ID Description Download PDF ProductTAG
89W Wall Guard White
89B Wall Guard Black
89S Wall Guard Stainless

ADA Compliant Recess Kit

Part ID Description Download PDF ProductTAG
40502 ADA Compliant Recess Kit

Noise Reduction Nozzle

Part ID Description Download PDF ProductTAG
62.2 1.1 Nozzle
34 Gasket
